| Specification | Value |
|---|---|
| Fire retardant version | yes |
| AWG-size | AWG32 |
| Pining | TIA/EIA 568 B |
| Color | Grey |
| Color anti-kink sleeve | Grey |
| Halogen free according to EN IEC 60754-1 | yes / no |
| Halogen free according to EN IEC 60754-2 | yes / no |
| Halogen free according to EN IEC 60754-3 | yes / no |
| Cable construction | 4x2 |
| Type of Cable | U/FTP |
| Category | KAT.6A (IEC) |
| Anti-kink sleeve | angespritzt |
| Copper Cable Construction | 4x2xAWG32/7 |
| Length | 0.25 m |
| Coating | LSZH |
| Color outer sheath | Grey |
| max. Data Transfer | 10 Gigabit |
| Oil resistant according to EN IEC 60811-404 | no |
| Pin assignment | 1:1 |
| Poe | yes |
| Locking lever | yes |
| Shield | U/FTP shielded |
| Type of Connector Connection 1 | RJ45 8(8) |
| Type of Connector Connection 2 | RJ45 8(8) |
| Product Number | Length | EAN Code |
|---|---|---|
| PKW-LIGHT-STP-K6 0.15 | 0.15 Meter | 9120064015961 |
| PKW-LIGHT-STP-K6 0.25 | 0.25 Meter | 9120064016043 |
| PKW-LIGHT-STP-K6 0.5 | 0.5 Meter | 9120064016128 |
| PKW-LIGHT-STP-K6 1.0 | 1.0 Meter | 9120064016203 |
| PKW-LIGHT-STP-K6 1.5 | 1.5 Meter | 9120064016289 |
| PKW-LIGHT-STP-K6 2.0 | 2.0 Meter | 9120064016524 |
| PKW-LIGHT-STP-K6 3.0 | 3.0 Meter | 9120064016685 |
| PKW-LIGHT-STP-K6 5.0 | 5.0 Meter | 9120064016760 |
| PKW-LIGHT-STP-K6 7.5 | 7.5 Meter | 9120064019204 |
| PKW-LIGHT-STP-K6 10.0 | 10.0 Meter | 9120064016364 |
| PKW-LIGHT-STP-K6 15.0 | 15.0 Meter | 9120064016449 |
| PKW-LIGHT-STP-K6 20.0 | 20 Meter | 9120064016609 |
